High Current Sensor

High Current Sensor product image

Use the High Current Sensor in experiments that involve currents larger than 1 A, such as solar panels, hand generators, and other alternative energy projects.

Description

The High Current Sensor has a range of ±10 A. Current is measured with a Hall Effect sensor, which uses the magnetic field created by the current and therefore does not add a resistive element to the circuit. A metal shield over the Hall Effect chip reduces the influence of external magnets. A replaceable fuse protects the equipment and circuit.

Sample Data

Videos

Specifications

  • High Current Sensor range ±10 A
  • Maximum voltage input ±40 V
  • Supply voltage 5 VDC
  • Typical Resolution: 4.9 mA
  • Output voltage range 0 – 5 V
  • Replaceable fuse 10 A
  • Current in amperes:

    • Slope 4.51 A/V
    • Intercept –11.31 A
Download the user manual for full specifications

Experiments and Lab Ideas

Lab Ideas and Innovative Uses

Experimenting with Solar Panels

Do you have an innovative use for Vernier technology? What about a favorite lab or demo? We love to hear what creative uses people have for our products. Please email them to innovativeuses@vernier.com

Compatibility Requirements

The High Current Sensor may require a compatible interface and software. Choose a platform below to see compatible interface and software options.

What’s Included

  • Vernier High Current Sensor
  • (1) extra 10 A fuse
  • User manual

Ordering Information
