Have you ever gone past a construction site or driven over a bridge and noticed that the supporting beams in a structure can be designed with a variety of cross-sectional shapes? In this activity, you will explore how changing the cross section of a beam affects the amount of deflection (or “bendiness”) a beam exhibits under a load. Your goal is to develop a model that will allow you to predict the relative deflection of a center-loaded beam supported on both ends based on its cross section shape.


  • Students will engage in an inquiry activity to develop a model based on observations (of their own devising) from the physical world.
  • Students will understand the factors that affect the deflection of a center-loaded beam, supported on both ends, with identical volume and mass of material, but with varied cross-sections.
  • Students will construct a model representing the relationship of the factors related to cross-section shape affecting the deflection of center-loaded beams.

Sensors and Equipment

This experiment features the following sensors and equipment. Additional equipment may be required.

Ready to Experiment?

Ask an Expert

Get answers to your questions about how to teach this experiment with our support team.

Purchase the Lab Book

This experiment is #2 of Materials Testing: Beams to Bridges with Go Direct® Structures & Materials Tester. The experiment in the book includes student instructions as well as instructor information for set up, helpful hints, and sample graphs and data.
