UVB Sensor


The UVB Sensor is an ultraviolet light sensor that responds primarily to UVB radiation (approximately 290 to 320 nm). It is ideal for experiments using sunlight as your UV source and is the sensor recommended for the UV experiments in our lab books.

Sample Data

Videos

Specifications

  • UV peak sensitivity: one volt per 204 mW/m2 at 315 nm
  • Wavelength sensitivity region, approximate: 290 to 320 nm, half-sensitivity points.
  • Dimensions: 21 cm by 2 cm diameter
  • Typical Resolution: 0.25 mW/m2
  • Time response: approximately 2 seconds to reach 95% of final reading
Download the user manual for full specifications

Experiments and Lab Ideas

Select a lab book to see a list of experiments and more information.

Lab Ideas and Innovative Uses

Do you have an innovative use for Vernier technology? What about a favorite lab or demo? We love to hear what creative uses people have for our products. Please email them to innovativeuses@vernier.com

Compatibility Requirements

The UVB Sensor may require a compatible interface and software. Choose a platform below to see compatible interface and software options.

What’s Included

  • Vernier UVB Sensor
  • Built-in light diffuser
  • User manual

Ordering Information

All prices are for U.S. educators.

NameOrder CodePriceQuantity
UVB SensorUVB-BTA$107

Support

Related Products

Educational use only: Vernier products are designed for educational use. They are not appropriate for industrial, medical, or commercial applications. Product usage disclaimer »
