Use the Gas Pressure Sensor to monitor pressure changes of a gas in chemistry and biology experiments.

Description

The Gas Pressure Sensor can be used to monitor pressure changes in a gas. The range is wide enough to perform Boyle’s law yet it is sensitive enough to conduct vapor-pressure or pressure-temperature experiments. Biology teachers can use the Gas Pressure Sensor to monitor transpiration or respiration in an enclosed environment.

Videos

Specifications

  • Pressure Range: 0 to 210 kPa (0 to 2.1 atm or 0 to 1600 mm Hg)
  • Maximum pressure that the sensor can tolerate without permanent damage: 4 atm
  • Resolution: 0.06 kPa (0.0006 atm or 0.45 mm Hg)
    (LabQuest 2, LabQuest, LabQuest Mini, Go!Link, LabPro)
  • Sensing Element: Honeywell SSCMRNN030PAAA5
  • Combined Linearity and Hysteresis: typical ±0.2% full scale
  • Response Time: 100 microseconds

Download the user manual for full specifications

Experiments and Lab Ideas

Select a lab book to see a list of experiments and more information.

Lab Ideas and Innovative Uses

What’s Included

  • Vernier Gas Pressure Sensor
  • (2) tapered valve connectors inserted into a No. 5 stopper
  • (1) tapered valve connector inserted into a No. 1 stopper
  • (1) two-way valve
  • (1) 18 inch Tygon tubing with Luer Lock connectors
  • (1) 20 mL syringe
  • (2) transpiration tubing clamps (white)
  • User manual

Sensor Requirements

The Gas Pressure Sensor requires a compatible interface and software to collect data. Interface and software sold separately. Getting started with probeware »

Compatible Interfaces

The Gas Pressure Sensor is compatible with these interfaces:

Ordering Information

All prices are for U.S. educators.

    NameOrder CodePriceQuantity
    Gas Pressure SensorGPS-BTA$83

    Educational use only: Vernier products are designed for educational use. They are not appropriate for industrial, medical, or commercial applications. Product usage disclaimer »

    Order Code GPS-BTA
    U.S. Educator Price $83

    Sample Data

    Boyle's Law on Logger <em>Pro</em> using the Vernier Gas Pressure Sensor.
    Boyle's Law on Logger Pro using the Vernier Gas Pressure Sensor.
    Pressure decreases as transpiration occurs
    Pressure decreases as transpiration occurs
