Go Direct® Fluorescence/UV-VIS Spectrophotometer

Go Direct® Fluorescence/UV-VIS Spectrophotometer

Go Direct® Fluorescence/UV-VIS Spectrophotometer

$2,999.00

The Go Direct Fluorescence/UV-Vis Spectrophotometer measures fluorescence and absorbance spectra of myriad samples, such as quinine sulfate, fluorescein, chlorophyll, and fluorescent proteins, all while connecting to your device via Bluetooth® wireless technology or USB.

ORDER CODE: GDX-SPEC-FUV Categories ,

Set your students up for success with the Go Direct Fluorescence/UV-VIS Spectrophotometer. Geared toward upper-level chemistry, this innovative device combines the functionality of a fluorometer with the power of a UV/VIS spectrophotometer. The Go Direct Fluorescence/UV-VIS Spectrophotometer allows students to conduct fluorescence data collection back-to-back with absorbance data collection in a single instrument. This supports quantum yield studies, quenching investigations, kinetics, Beer’s law, and simple fluorescence detection with samples such as quinine sulfate, DAPI, GFP, and tryptophan. Excitation LEDs included are 375 nm, 450 nm, and 525 nm—other wavelengths can be purchased separately. Inquire about custom wavelengths. To conduct emission spectra experiments, simply attach the Vernier Spectrophotometer Optical Fiber

Additionally, the Go Direct Fluorescence/UV-VIS Spectrophotometer connects directly to a tablet, computer, or LabQuest®, offering students the flexibility to work with many technologies used in chemistry labs. Data can be collected and analyzed using our LabQuest 2, LabQuest 3,  Logger Pro® software, or free Vernier Spectral Analysis® software, which allows users to spend less time learning different interfaces and more time in the laboratory.

Specifications

  • Detection modes: Absorbance,  Fluorescence, %Transmittance, Intensity, and Raw Lamp
  • Experiment types:  Full Spectrum, time-based (kinetics), and event-based (Beer’s law)
  • Dimensions: 18.5 cm × 17.0 cm × 7.0 cm
  • Lamp power supply: AC adapter (included)
  • Bluetooth power supply: USB (USB adapter Included)
  • Power consumption: 3 A start-up, 500 mA continuous
  • Absorbance light source: Deuterium (UV) and incandescent (VIS)
  • Emission light source: Exchangeable LED (ships with 375 nm, 450 nm, and 525 nm)
  • Detector: Linear CCD
  • Wavelength range: 220–850 nm
  • Wavelength reporting interval: ~1 nm
  • Optical resolution: 3.0 nm (as determined with 486 nm hydrogen emission spectral line FWHM)
  • Wavelength accuracy: ±2.0 nm (as determined with holmium oxide NIST standards)
  • Absorbance photometric accuracy: ±5.0% (as determined with potassium dichromate NIST standards)
  • Absorbance photometric range (for best accuracy): 0.1–1.0
  • Typical scan time: ~2 s
  • Sample format: 10 mm × 10 mm cuvette (UV fluorescence cuvette included)
  • Fluorescence emission detection limit: 1 mg/L quinine sulfate dihydrate in 0.1 M H2SO4

Experiments

College (9 experiments)

Free Experiment Downloads

Preview and/or edit the spectroscopy experiments for your curriculum by downloading a zip file for each of the experiments below. Each experiment’s zip file contains two student versions (one for use with Logger Pro®/LabQuest® and one for Vernier Spectral Analysis®) as well as an instructor version. The Student download includes objectives, materials, procedures, and analysis for use with Vernier Spectral Analysis®, LabQuest®, or Logger Pro®. The Instructor download includes notes, sample results and graphs, and answers.

Requirements

Choose a platform below to see its compatibility requirements.

LabQuest
InterfaceLabQuest App
LabQuest 3Full support 1
LabQuest 2 (discontinued)Full support 1
LabQuest (discontinued)Incompatible

Compatibility Notes

  1. Connect this sensor via USB. Wireless data collection is not supported.
Computers
Software
InterfaceSpectral Analysis for ComputersGraphical Analysis App for ComputersLogger Pro
No interface requiredFull support 1IncompatibleFull support 2
LabQuest 3IncompatibleFull support 3Incompatible
LabQuest 2 (discontinued)IncompatibleFull support 3Incompatible

Compatibility Notes

  1. For Bluetooth® connectivity, only computers running Windows 10 or Mac OS X 10.10 or newer are supported. The computer must also have a compatible Bluetooth 4.0+ radio.
  2. Connect this sensor via USB. Wireless data collection is not supported.
  3. Connect this sensor directly to a computer or Chromebook via a USB or wireless Bluetooth® connection and use with Spectral Analysis App for best results. Alternatively, this sensor is fully supported when used via USB with LabQuest 2 or LabQuest 3 when the LabQuest is connected to a computer or Chromebook via Wireless Data Sharing.
Chromebook
Software
InterfaceSpectral Analysis for ChromeGraphical Analysis App for Chrome
No interface requiredFull supportIncompatible
LabQuest 3IncompatibleFull support 1
LabQuest 2 (discontinued)IncompatibleFull support 1

Compatibility Notes

  1. Connect this sensor directly to a computer or Chromebook via a USB or wireless Bluetooth® connection and use with Spectral Analysis App for best results. Alternatively, this sensor is fully supported when used via USB with LabQuest 2 or LabQuest 3 when the LabQuest is connected to a computer or Chromebook via Wireless Data Sharing.
iOS
Software
InterfaceSpectral Analysis for iOSGraphical Analysis App for iOSGraphical Analysis GW for iOS
No interface requiredFull supportIncompatibleIncompatible
LabQuest 3IncompatibleFull support 1 2Full support 1 2
LabQuest 2 (discontinued)IncompatibleFull support 1 2Full support 1 2

Compatibility Notes

  1. iOS and Android devices can only connect to LabQuest 2 or LabQuest 3 via Wireless Data Sharing.
  2. Connect this sensor directly to an iOS or Android™ device via wireless Bluetooth® connection and use with Spectral Analysis App for best results. Alternatively, this sensor is fully supported when used via USB with LabQuest 2 or LabQuest 3 when the LabQuest is connected to an iOS or Android device via Wireless Data Sharing.
Android
Software
InterfaceSpectral Analysis for AndroidGraphical Analysis App for AndroidGraphical Analysis GW for Android
No interface requiredFull supportIncompatibleIncompatible
LabQuest 3IncompatibleFull support 1 2Full support 1 2
LabQuest 2 (discontinued)IncompatibleFull support 1 2Full support 1 2

Compatibility Notes

  1. iOS and Android devices can only connect to LabQuest 2 or LabQuest 3 via Wireless Data Sharing.
  2. Connect this sensor directly to an iOS or Android™ device via wireless Bluetooth® connection and use with Spectral Analysis App for best results. Alternatively, this sensor is fully supported when used via USB with LabQuest 2 or LabQuest 3 when the LabQuest is connected to an iOS or Android device via Wireless Data Sharing.

What's Included

  • Go Direct Fluorescence/UV-VIS Spectrophotometer
  • AC Power Supply
  • Fluorescence quartz cuvette
  • Mini USB Cable
  • USB Power Adapter
  • LED cartridges (3): 375 nm, 450 nm, 525 nm

Accessories

AccessoryOrder CodePriceQuantity
Fluorescence LED Cartridges - 280 nmVSP-280$439.00
Fluorescence LED Cartridges - 350 nmVSP-350$176.00
Fluorescence LED Cartridges - 400 nmVSP-400$88.00
Vernier Spectrophotometer Optical FiberVSP-FIBER$74.00
Mini USB-C CableCB-USB-C-MINI$9.00
Fluorescence LED Cartridges - 500 nmVSP-500$88.00
Fluorescence LED Cartridges - 525 nmVSP-525$80.00
Replacement PartOrder CodePriceQuantity
Mini USB CableCB-USB-MINI$5.00
Quartz CuvettesCUV-QUARTZ$219.00
Fluorescence LED Cartridges - 280 nmVSP-280$439.00
Fluorescence LED Cartridges - 350 nmVSP-350$176.00
Fluorescence LED Cartridges - 375 nmVSP-375$90.00
Fluorescence LED Cartridges - 400 nmVSP-400$88.00
Fluorescence LED Cartridges - 450 nmVSP-450$88.00
Fluorescence LED Cartridges - 500 nmVSP-500$88.00
Fluorescence LED Cartridges - 525 nmVSP-525$80.00
Fluorescence/UV Quartz CuvetteCUV-QUARTZ-FUV$199.00
Replacement Power Supply for UV-VIS and Fluorescence/UV-VIS SpectrophotometerVSP-UV-PS$35.00

Support

Educational use only: Vernier products are designed for educational use. They are not appropriate for industrial, medical, or commercial applications.
