Select a Region

Select a region for additional data analysis

  1. Click or tap and drag across the graph to select a region
  2. If needed, drag the boundary lines to resize the region

Apply a Curve Fit to a Selected Region

Analyze a selection of your data

  1. Select a region
  2. Click or tap the Graph Tools button
  3. Select a curve fit model
  4. Click or tap Apply or somewhere outside the selection tool to view the equation

Apply a Curve Fit to All Data

Analyze data in the region defined by the graph’s x-axis range

  1. Click or tap the Graph Tools button
  2. Select a curve fit model
  3. Click or tap Apply or somewhere outside the selection tool to view the equation

Note: Data having x-coordinates within the graph’s x-range will be included in the analysis even if they are not plotted on the graph.

Calculate Statistics

Find the mean, standard deviation, minimum, and maximum values of the data

  1. Click or tap the Graph Tools button
  2. Select Statistics
  3. If needed, scroll the text in the Statistics dialog to view all of the information

Note: You can also calculate statistics for a portion of the data by first selecting a region.

Plot Data from Multiple Data Sets

Add or remove the columns of data plotted on any graph

  1. Click or tap the y-axis label to display the selection popover
  2. Click or tap a column to add or remove it from the graph
  3. Click or tap off of the popover to dismiss the tool

Creating a Calculated Column

  1. Click or tap the options button (ᐧᐧᐧ) in one of the table columns
  2. Select Add Calculated Column
  3. Modify the Name, Units and Displayed Precision as desired
  4. Click or tap Insert Expression and select the desired expression
  5. Modify the expression as necessary
  6. Click or tap Apply

Note: When the data column upon which the calculated column is based is plotted, the graph will update to show the new calculated column instead.

About Spectral Analysis 4

Spectral Analysis 4

Our free Spectral Analysis app makes it easy to incorporate spectroscopy into your biology and chemistry labs. Using the app, students can collect a full spectrum and explore topics such as Beer’s law, enzyme kinetics, and plant pigments. Learn more about Spectral Analysis 4 »
