Have you ever done an experiment that you wish you could repeat with different chemicals or concentrations but lacked the time and materials? This is where Pivot Interactives new activities for chemistry can become a valuable teaching tool.
Pivot Interactives is a browser-based collection of videos and analysis tools that enable students to control real results—not simulations. The videos come with appropriate tools for measuring volume, mass, temperature, time, and even color intensity. There are additional tools to carefully control the progression of the video and experiment. Online tables and graphs are used for students to graph relationships between the variables being studied. Calculated columns can be built and graphed.
Topics include Beer-Lambert law, acid-base titration, kinetics, rate laws and activation energy, gas laws, density, specific heat, and more.
Wait until you see how the “black box” around a colorimeter or spectrometer is stripped away to show the essence of how the device measures transmittance and absorbance. The students use their own eyes as the detector with a clever combination of tools and filters to determine the appropriate wavelength to use for the experiment.
Many teachers are interested in using our EKG sensors to record an electromyogram (EMG), the electrical activity produced from muscle contractions. Recording an EMG is straightforward, but there are multiple ways that an EMG can be analyzed. The most robust technique is to measure the integral of the rectified EMG signal, which can easily be done using the Go Direct EKG Sensor.
A normal EMG has both positive and negative deflections. A rectified EMG uses a function that makes all of the EMG deflections positive—the larger the integral, the larger the muscle contraction. In the past, we have offered special Logger Pro and LabQuest files that provide the proper filtering and calculated column support to record and analyze rectified EMGs. But, the Go Direct EKG Sensor makes recording rectified EMGs much simpler. No special files or filter settings are required—just change the channel to EMG Rectified and start collecting data. Then simply measure the integral of the signal in Graphical Analysis.
The sample graph shows an example of an EMG and rectified EMG recorded from the forearm using Go Direct EKG. A digital high-pass filter that has been optimized for recording EMGs is automatically applied to the EMG channel. The EMG Rectified channel returns the absolute value of the EMG channel, making all of the EMG deflections positive.
To analyze the rectified EMGs, simply select the region of the rectified EMG you want to analyze and use the View Integral feature in Graphical Analysis 4. You can even compare the integrals of different rectified EMGs to see which condition produced less or more muscle activity. For example, in the sample graph, the area of the rectified EMG increases with each burst of activity. The first, second, and third rectified EMGs have areas of 0.181, 0.329, and 0.441 mV s.
Photosynthetic organisms such as plants and algae use electromagnetic radiation from the visible spectrum to drive the synthesis of sugar molecules. Special pigments in chloroplasts of plant cells absorb the energy of certain wavelengths of light, causing a molecular chain reaction known as the light-dependent reactions of photosynthesis. The best wavelengths of visible light for photosynthesis fall within the blue range (425–450 nm) and red range (600–700 nm). Therefore, the best light sources for photosynthesis should ideally emit light in the blue and red ranges. In this study, we used a Go Direct® SpectroVis® Plus Spectrophotometer with a Vernier Spectrophotometer Optical Fiber and LabQuest 2 to collect spectra from four different light sources. This allowed us to determine the wavelengths emitted by each source and to get an idea of their relative intensities.
Wavelengths of light outside of the red and blue ranges are not used by most plants, and can contribute to heat build-up in plant tissues. This heat can damage plants and even interfere with photosynthesis. In order to identify the ideal light source for photosynthesis studies we compared the output or emission spectra of four different E27 type bulbs in the same desk lamp: a) 60 W incandescent bulb, b) 35 W halogen bulb, c) 28 W-equivalent LED “plant bulb” (6–9 W), and d) 13 W compact fluorescent light (CFL) bulb. Each light was measured at a standard distance of 50 cm.
Based on our results, the best light bulb for promoting photosynthesis in plants was the LED plant bulb. This bulb produces a strong output in both the blue and red wavelengths, with very little additional light in other regions to cause heat build-up. All of the other light sources had very little output in the blue range. The halogen and incandescent bulbs had extremely broad output ranges from green to deep into the red portion of the spectrum, but with little to nothing in the blue range. The least suitable lamp for photosynthesis was the CFL bulb. While it emitted some light in both the blue and red ranges (with several peaks in between), the intensity of this bulb was the weakest when compared to all the other lamps. LED plant lights are available from a variety of online merchants and home and garden stores. They have become very affordable, and work well for experiments that investigate photosynthesis.
Marta L. Dark and Derrick J. Hylton; Journal of College Science Teaching, 2018, (47) 3.
If you take the Physics and the Arts course at Spelman College in Atlanta, Georgia, you will be exposed to many applications of a traditional physics class as they apply to various areas in the arts. Light, color, sound, gravity, equilibrium, and space time are some of the topics that are explored. Students explore the topics with a guided inquiry approach. At the end of the course, students create artwork that illustrates a physical concept. Students use a Go Direct® SpectroVis® Plus Spectrophotometer and Logger Pro 3 software while they study aspects of color and light.
Enhancing a Scientific Inquiry Lesson Through Computer-Supported Collaborative Learning
Kathleen Koenig, Janet Mannheimer Zydney, Doug Behr, and Lei Bao; Science Scope, September, 2017.
In this guided inquiry activity, students learn about energy transformations as they apply to renewable energy. Students use the KidWind Basic Wind Experiment Kit to design windmill turbines that result in the highest energy output. The students research about how windmill blades work, and brainstorm which designs are most likely to produce the highest output. Students are expected to be able to identify controls, independent variables, and dependent variables. They also demonstrate how they control those variables in their designs. They develop prototypes that they test with a box fan. After initial tests, they modify their design to improve energy output. This project is closely linked to NGSS and CAST standards.
Where Does The Energy Go?
Marta R. Stoeckel (Tartan High School, Oakdale, MN); The Science Teacher, Vol. 85, No. 1, January, 2018.
This article explains how to use evidence-based reasoning to study the bounce of a ball. It is linked to NGSS standards and the authors use Logger Pro 3 video analysis to plot a ball’s position.
Burst Mode Composite Photography for Dynamic Physics Demonstrations
James Lincoln; The Physics Teacher, May, 2018.
Many digital cameras, and even camera phones, have “burst mode.” This allows the cameras to take a series of photos in rapid succession. The author explains how to take and composite these photos, which results in one image showing the photos overlaid. If a moving object is in the scene, you can use our photo analysis to get distance, velocity, and acceleration data of that image.
Heat Evolution and Electrical Work of Batteries as a Function of Discharge Rate: Spontaneous and Reversible Processes and Maximum Work
Robert J. Noll and Jason M. Hughes; J. Chem. Educ., 2018, 95, pp 852−857.
This article describes an experiment in which students compare the enthalpy change of the useful electrical work to the heat lost from the electrochemical reaction in batteries. AA alkaline batteries are installed in a battery holder and connected to a heater resistor and sensors. The apparatus is suspended in a Dewar flask and the water is stirred gently at 200 rpm. The potential, current, and temperature are measured over a period of 30 minutes. The students use a Current Probe and a Voltage Probe connected to a computer running through a LabQuest Mini to measure the work output of the battery. The waste heat produced is measured calorimetrically using a Stainless Steel Temperature Probe. This activity combines concepts from electricity, electrochemistry, and thermodynamics in one experiment.
Measuring the Force between Magnets as an Analogy for Coulomb’s Law
Samuel P. Hendrix and Stephen G. Prilliman; J. Chem. Educ., 2018, 95, pp 833−836.
The authors describe a simple demonstration to illustrate the relationship between charged particles as described by Coulomb’s law. They use a Dual-Range Force Sensor mounted on a LEGO® platform. The sensor is connected to a computer with a Go!Link and monitored with our free Logger Lite software. A neodymium magnet is attached to the end of a screw. It is installed where the hook or bumper would normally go in the sensor. A second neodymium magnet is mounted to another LEGO® piece that is mounted on the same LEGO® platform. Attractive and repulsive forces can be demonstrated by switching the orientation of one of the magnets. The force between the magnets is plotted as a function of distance using the Events with Entry mode of data collection. This plot represents a Coulomb’s law force between charged particles and would be useful when teaching ionization, bonding, intermolecular forces, lattice energy, and PES (photoelectron spectroscopy).
Using Open-Source, 3D Printable Optical Hardware To Enhance Student Learning in the Instrumental Analysis Laboratory
Eric J. Davis, Michael Jones, D. Alex Thiel, and Steve Paul; J. Chem. Educ., 2018, 95, pp 672−677.
The authors describe the ability to use 3D printing technology to construct analytical instruments. They also discuss how to make the components of an absorbance spectrometer. Various mounts, posts, and slits are printed on a 3D printer are mounted on a platform with lenses and diffraction gratings with light sources and detectors. Even cuvette holders are fabricated. Common full-absorption spectra and Beer’s law plots are done with copper (II) sulfate solution. The results are compared to those from a Go Direct® SpectroVis® Plus Spectrophotometer. The plots of absorbance vs. wavelength and absorbance vs. concentration from the 3D-printed spectrometer compare favorably with those produced by the SpectroVis Plus.
Penny Snetsinger and Eid Alkhatib; J. Chem. Educ., 2018, 95, pp 636−640.
The goal of this activity is to provide students with the opportunity to design an experiment that studies the effect of activated carbon on dyes. Students select dyes to study as well as conditions to vary such as pH, salinity, water hardness, and time of contact between the dye and the carbon. The experiment lasts multiple weeks to provide ample time for the students to vary experiment conditions and to analyze their results. Additionally, students use various analytical statistics and techniques to evaluate the outcome of their experiments. They also employ a factorial experiment design that allows them to simultaneously vary more than one variable. They used a Beer-Lambert plot to spectrophotometrically determine the concentration of dye left in the solution after exposure to the activated carbon. Students use a Go Direct® SpectroVis® Plus Spectrophotometer in this experiment.
Physicians as the First Analytical Chemists: Gall Nut Extract Determination of Iron Ion (Fe2+) Concentration
Mary T. van Opstal, Philip Nahlik, Patrick L. Daubenmire, and Alanah Fitch; J. Chem. Educ., 2018, 95, pp 456−462.
This article describes a guided inquiry activity that measures the iron in drinking water, using oak gall nut extract. This activity is geared toward students who are interested in medical careers. The idea is to use a naturally occurring substance to react with the iron ion in a solution and to form a colored solution from which the iron concentration can be determined. The students create standard Beer-Lambert plots of absorbance vs. concentration, then measure the absorbance of the gall-iron solution to determine the concentration of the iron ion. In this experiment students use a Go Direct® SpectroVis® Plus Spectrophotometer.
Measuring Yeast Fermentation Kinetics with a Homemade Water Displacement Volumetric Gasometer
Richard B. Weinberg; J. Chem. Educ., 2018, 95, pp 828−832.
This article describes how to build a volumetric gasometer from simple equipment such as plastic bottles and tubing. The students then use the device to measure the volume of carbon dioxide produced while sugar is metabolized by yeast. As the CO2 is produced the water in one bottle is displaced into a second bottle. The rate of metabolism is measured by timing the amount of water displaced. The activity is appropriate for students from middle school well into college and describes how to use the experiment with different age groups. Some of the inspiration for this activity came from Experiment 12A, “Respiration of Sugars by Yeast” from our Biology with Vernier lab book and “Sugar Metabolism with Yeast” from our lab book Investigating Biology through Inquiry.
In July, more than 100 students from 35 countries used our Go Direct sensors to test the water in Ireland’s Killarney National Park as part of the 2018 GLOBE Learning Expedition (GLE). This event is part of the GLOBE Program and is held every few years in different locations around the world. The GLE brings together students, teachers, and scientists for a week of sharing and learning about science, the environment, and each other’s cultures. As part of this year’s student field experience, Go Direct sensors were used to measure temperature, pH, conductivity, and dissolved oxygen levels along the Deenagh River. This beautiful river runs along the edge of the park, near the town of Killarney. The students’ sensor data, along with a survey of macroinvertebrates, indicated that the Deenagh is in excellent health.
Using Go Direct sensors wirelessly in this type of environment was a game-changer for many students and their teachers. The new Go Direct® Optical Dissolved Oxygen Probe was especially useful as it reports not only dissolved oxygen concentration, but temperature and atmospheric pressure as well. By connecting Go Direct sensors via Bluetooth® wireless technology, one student can stay safely on the shore with a LabQuest 2, mobile phone, or other device, while another student holds the sensor in the water. Everyone agreed that the simplicity and accuracy of Go Direct sensors make them an excellent choice for students conducting field work.
We are proud to work with the GLOBE Program, an international science and education program whose mission is to promote the teaching and learning of science, enhance environmental literacy and stewardship, and promote scientific discovery. For more information, visit the GLOBE Program page»
This guide has many useful resources for incorporating climate change lessons into science programs and has been mailed to science teachers at every school in seven states. It is also available as a free download.
You can now use our wireless Go Direct sensors with the Digital Control Unit (DCU) to control small electronic devices (e.g., motors, LEDs, and lights). Last year, you may recall, we added the capability to control the DCU from LabQuest 2. This year, when LabQuest 2 gained the ability to connect with Go Direct sensors, we once again expanded the DCU’s capability. Wirelessly connect your Go Direct sensor(s) to LabQuest 2, connect the DCU to LabQuest 2, and program the DCU to turn on components based on the sensor values.
With Go Direct sensors and the DCU, you can use output from a heart rate monitor to light up LEDs that help test subjects maintain a target heart rate. Or, if your students struggle to stay awake, you can have them create an alarm that triggers when carbon dioxide levels get too high in your classroom. You could even program a fan to turn on and bring in some fresh air!
We have also created a kit of components that run on DC power in order to make it easier for you to integrate the DCU into your classroom. The Digital Control Unit Power Output Kit contains lights, LEDs, and a motor, along with connecting wires. We believe this will make it much easier to integrate simple programming logic, the engineering design process, and process control concepts into your science or engineering classroom.
For those of you who may be new to the Digital Control Unit, the device is designed to turn on a DC powered electrical component based on simple logic statements (greater than or equal to, or less than or equal to) associated with sensor values or time. It can be set up and controlled in Logger Pro 3 software or the LabQuest app. Compound statements using “and”, “or”, “until” statements allow for fairly complex control. For more information go to Digital Control Unit page.
Instrumentation is used in the undergraduate chemistry curriculum to help demonstrate the fundamental aspects of chemical reactions and demonstrate how it can be used to determine certain properties of a chemical system. For example, absorbance spectroscopy teaches students about transmission and absorption of radiation by a compound and how these measurements can be used to determine concentration or chemical reaction order. Chromatography illustrates to students how the structure of compounds can help isolate them from others. When certain techniques are coupled together, the concepts are layered and even more can be learned about the system being studied.
Flash photolysis spectroscopy is a type of time-resolved absorbance spectroscopy that helps students investigate chemical reaction order as well as the basics of photochemistry. Flash photolysis is often referred to as a “pump-probe technique” because it involves an excitation source or a “pump” and a detection source or a “probe”. This technique was so groundbreaking that the 1969 Nobel Prize in Chemistry was awarded to the scientists who developed it.
The diagram below shows a typical flash photolysis setup. In this system, white light from an LED light source probes any spectral changes made in the system by the excitation light pulse. A xenon flash lamp provides the photo-excitation pulse. The white light from the LED source is focused on the sample. From the sample this beam goes through a wavelength filter as it is focused on a photodiode, which detects this light’s intensity. When the xenon lamp is flashed, an intense near-UV, white light pulse enters the sample. If it causes changes in the absorption of the sample at the filter’s wavelength, the detector measures these changes. The voltage from the detector is collected, digitized, and stored as a function of time.
With recent advances in photochemistry in a number of disciplines, understanding photo-induced chemical kinetics is quickly becoming an essential part of the undergraduate chemistry curriculum. Due to limitations in affordable instrumentation, photochemical kinetics is often left to the textbook alone. The Vernier Flash Photolysis Spectrometer is an affordable option available to instructors to help students get hands-on experience with this important technique. We provide a number of free experiments to get you started, including one that involves exploration of a simple light-induced, cis-trans isomerization of Congo Red. Congo Red is a diazo dye that is a derivative of azobenzene. When light excites the ground state trans- form at its visible broadband absorbance, some ground state molecules are converted to a higher energy cis- form instantaneously (on this time scale, at least). The cis- state is metastable with respect to the trans- ground state resulting in slow conversion back to this trans- ground state, as shown in the state diagram below. The loss of the absorbance at 600 nm observed by the Vernier Flash Photolysis Spectrometer gives students the opportunity to follow the progress of a thermal cis-trans isomerization and measure its rate on timescales that cannot be achieved by traditional mixing methods.
The data and analysis provides an opportunity for discussion with students about various topics, including perturbation kinetics, photochemistry, fast kinetics, and bimolecular rate constants. This experiment, and others like it, allow for easy incorporation of time-resolved spectroscopy into the undergraduate physical chemistry, biochemistry, organic chemistry, and inorganic chemistry curriculums.
At Vernier, we focus on sourcing from local venders, generating our own solar power, and providing our employees with annual TriMet passes to encourage the use of public transpiration. Our building is also LEED Gold certified. Vernier employees participate in multiple commuter challenges, such as the Bike More Challenge, that encourages participants to ride their bikes to work. Our two on-site, certified Master Recyclers work with many local recycling organizations to prevent recyclable materials from ending up in landfills, and our Green Team of Vernier employees continues to make improvements to our processes and encourage sustainability throughout the company. We are also founding members of the Oregon Business Alliance for Climate and have signed the We Are Still In pledge.
The awards were announced in the June 2018 edition of Oregon Business Magazine. For more information about the sustainable practices that we implement every day, visit our environment page.
